Cresnet supports up to 252 keypads and other devices.Ĭameo Standard Mount Keypads are designed for installation in a standard electrical wall box, making them perfect for installation in a multi-gang box alongside other low-voltage devices. Cresnet is a simple, yet flexible 4-wire network that provides bidirectional communication and 24 VDC power for Cresnet devices. The Cresnet bus is the communications backbone for many Crestron keypads, lighting controllers, shade motors, sensors, and other devices. Using the control ports, it's possible to add monitoring of room occupancy, ambient light level, door closures, and other conditions without having to home run extra wiring to the central equipment location. Two digital/analog input ports onboard the C2N-CBD-P provide a local interface for a range of devices including the Crestron GLS Series Occupancy Sensors and Photosensors or any device providing a contact closure, DC logic, or 0-10 VDC. In addition to controlling the backlight and LED intensity, the built-in light sensor can also be utilized by the control system to support basic daylight harvesting and other programmatic functions. Auto-dimming LED intensity ensures optimal visibility under varying lighting conditions. Onboard bar graph logic allows the feedback LEDs to function as a 6-segment bar graph display, providing clear level indication when adjusting lighting and audio settings. Ten flash patterns are built in, enabling flashing LED feedback with simplified programming and reduced traffic on the Cresnet® network. Six pinhead-sized white LEDs provide fully customizable feedback to show the status of each button. A built-in light sensor controls the backlight intensity automatically to achieve crisp, legible text in both darkened and fully lit rooms. High-quality backlit laser engraving 1 provides customizable button text that's easy to read under any lighting condition. In addition, shift key functionality is possible, allowing any button to be held while pressing another to provide further customization for the keypad. Through programming, each button can be configured for up to three separate functions.
Button caps may also be ordered with custom backlit laser engraving 1 to clearly designate each button's function. Each keypad is furnished with an assortment of button caps in four different sizes to support a variety of physical layouts.
Simple yet highly customizable, a single Cameo Keypad can be configured easily by the installer to provide from two to eight buttons. The C2N-CBD-P easily installs alongside other low-voltage in-wall devices to deliver an advanced custom keypad control solution as part of a complete Crestron control system. The Cameo® Standard Mount Keypad (C2N-CBD-P) from Crestron® presents a fresh, innovative concept in keypad design, featuring a highly configurable one-gang wall mount form factor.
